Sucicago Fuel Sender Marine For Truck Vehicle 240-33Ohms 5”(130Mm) Boat Fuel Level Sending Unit Fuel Gauge Sending Unit

Description

Sucicago Stainless Steel Marine Fuel Sending Unit Is Much More Accurate And Reliable Than The Old Arm And Float Setup. Customer Can Purchase In Conjunction With A Sucicago Fuel Level Gauge Or Water Level Gauge. They’Re Designed To Monitor The Fuel, Diesel,Gasoline Or Water Level In The Tank. This Marine Fuel Tank Sending Unit Will Also Work With Any Fuel/Water Level Gauge With Signal Range 240-33 Ohms (Empty – Full).Body Material : Stainless Steel Cable: Pvc Nbr.Gasket: 1Pc Metric Stainless Steel Screws: 5Pcs Mounting Methods: Standard Sae 5 Hole Pattern. Protection Rank: Ip67. Output Signal: 240-33Ohms (240 Ohms At Empty, 0 Ohm At Full)). Resolution Range:10Mm For The Length Of Sucicago Sender 4,5,6,721Mm For The Length Of Sucicago Sender 8,9,10,11,12,13Package Information:1 X Sucicago Fuel Sending Unit 1 X Gasket 5 X M5*0.8 Length(16Mm) Screws 1X Sending Unit InstallationProper Wiring Installation:-Connect Ground (Blue) Wire From Sucicago Sending Unit To A Common Grounding Hook-Up.-Connect Signal (Brown) Wire From Sucicago Sending Unit To Gauge Hook-Up. If Your Gauge Has Color Coded Hook-Ups, Maintain This Coding As You Connect The Sender And Ground Wires.
